Porsche 924S Instrument Cluster Teile

Pos	__Part_Number__	Description	Remark	Qty.	Model
		instrument cluster
		sender
1	944 641 310 02	instrument cluster		1
2	944 641 211 01	tachometer		1
		with
		consumption indicator
		F >>92HN4 52624
2	944 641 211 02	tachometer		1
		without
		consumption indicator
		F 92HN4 52625>>
2	944 641 215 01	tachometer		1	AUT.
3	944 641 117 02	oil pressure indicator		1
4	A 944 641 015 02	clock		1
4	944 641 015 BX	clock		1
5	944 641 119 01	voltmeter		1
6	900 631 132 90	bulb		X
		12V, 1,2W
7	477 919 213	bulb socket		X
		single pole
8	928 641 927 00	bulb socket		1
9	321 919 115 C	retaining bar		2
10	477 919 115	retaining bar		1
11	411 957 117	knurled nut		5
		M 4
12	999 631 301 90	bulb		7
13	111 919 243	bulb socket		1
(15)	477 919 235	combination warning light		1
16	477 919 307	cigarette lighter		1
17	644 652 112 00	glower		1
-	N 012 469 1	circlip		1
		for
		cigarette lighter

Pos	__Part_Number__	Description	Remark	Qty.	Model
18	928 606 203 01	oil pressure sender		1
19	N 012 224 3	spring washer		2
		B 4
20	N 011 004 6	hexagon nut		2
		M 4
21	944 606 201 00	temperature sensor		1
22	N 013 806 2	sealing ring		1
23	477 945 515	brake light switch		1
24	481 945 529	nut		1
		M 12
25	084 941 521	switch		1
26	900 123 106 30	sealing ring		1
27	944 606 125 00	temperature sensor		1
28	900 123 101 30	sealing ring		1
29	477 919 051 B	tank gauge		1
30	477 919 133	sealing ring		1
31	N 013 802 1	sealing ring		5
32	N 044 734 1	pan-head Schraube		5
		M 5 X 16
