Porsche 924 Door Teile

Pos	__Part_Number__	Description	Remark	Qty.	Model
		door
(1)	477 831 051 H	door in white	Left	1	TURBO
		F >>93AO1 50362			(USA)
(1)	477 831 052 H	door in white	Right	1	TURBO
		F >>93AO1 50362			(USA)
1	477 831 051 AA	door in white	Left	1
		prepared for
		door mirror
(1)	478 831 052 R	door in white	Right	1
		prepared for
		door mirror
(1)	477 831 052 AA	door in white	Right	1
		not prepared for
		door mirror
1A	477 831 139 C	reinforcement	Left	1
		door mirror
(1A)	477 831 140 C	reinforcement	Right	1
		door mirror
1B	928 531 235 03	threaded piece		2
1C	N 013 295 1	tensioning sleeve		2
2	171 831 403	hinge half		4
3	321 831 421	hinge pin		4
5	928 537 419 03	pan-head Schraube		2
6	944 537 091 00	door seal	Left	1
(6)	944 537 092 00	door seal	Right	1
6A	477 837 233	additional gasket		2
		F >>92CN4 01894			924 (J)
		F >>92CN4 50556	N)		924 (USA)(CD
		F >>93CN1 50254	CDN)		TURBO (USA)(
6B	477 837 235	additional gasket		2
		F >>92CN4 01894			924 (J)
		F >>92CN4 50556	N)		924 (USA)(CD
		F >>93CN1 00246			TURBO (J)
		F >>93CN1 50254	CDN)		TURBO (USA)(
8	900 119 052 02	pan-head Schraube		8
		M 8 X 15

Pos	__Part_Number__	Description	Remark	Qty.	Model
9	900 027 015 02	lock ring		8
		B 8
10	823 711 815	washer		8
11	944 537 609 00	door support		2
11	944 537 609 00	door support		2
12	N 011 524 7	washer		4
		B 6
13	900 067 009 02	pan-head Schraube		4
		M 6 X 15
14	928 537 417 02	bearing bracket	Left	1
(14)	928 537 418 02	bearing bracket	Right	1
15	928 537 425 02	desk pad	Left	1
(15)	928 537 426 02	desk pad	Right	1
16	928 537 459 02	oval-head Schraube		4
		M 6 X 20
17	477 831 155	reinforcement		2	M 190
18	999 147 006 02	oval-head Schraube		4	M 190
		M 8 X 16
19	N 012 133 1	shake-proof washer		4	M 190
		V 8,4
20	477 971 910	bellows		2
